Drum scraper forming machine is a kind of internal heating conduction type rotary continuous drying equipment.The rotating drum adheres to a thickness of material film through its lower material groove, and the heat is transported to the inner wall of the drum through the pipeline, conducted to the outer wall of the drum, and then conducted to the feeding film, so that the humidity in the material film is evaporated and dehumidified, so that the material containing moisture is dried.The dried material is shoveled away from the drum by the scraper installed on the surface of the drum, and then placed under the scraper screw conveyor, through which the dry material is concentrated and packaged.
Capacity | 1500kg/h（Dry materials 95%），1300kg/h（Dry material 97%） | ||
Model | HD-2000T | ||
Size | 2630*4800*4004mm | ||
Weight | 12500kg | ||
RPM | Drive roll reducer | 0—8轉(zhuǎn)/分鐘 | |
Sub-roller reducer | 0—30轉(zhuǎn)/分鐘 | ||
Screw conveyor reducer | 0—29轉(zhuǎn)/分鐘 | ||
Manual turbo reducer | 1/60 | ||
Power Supply | 380V / 3P+N+G / 60Hz | ||
Power | Drive roll reducer | 15 KW | |
Sub-roller reducer | 4 KW | ||
Screw conveyor reducer | 4 KW | ||
Compressed air | Pressure | 0.6mpa | |
